Pressure Gauge KGB4
Features
Mechanical pressure gauge
- With liquid-filled case for applications with high dynamic pressure loads or vibrations
- For gaseous and liquid aggressive media that are not highly viscous or crystallising, also in aggressive ambience
- Process industry: Chemical/petro-chemical, power stations, mining, on- and offshore, environmental technology, machine building and general plant construction
Technical Data
| Housing | |
|---|---|
| Nominal size | 50 mm |
| Case material | Stainless steel 1.4301 / AISI 304 |
| Type of housing | Crimped bezel ring |
| Bezel ring material | Stainless steel 1.4301 / AISI 304 |
| Window material | Polycarbonate |
| Window gasket | Elastomer |
| Protection rating (EN 60529) | IP55 |
| Dial | White, aluminium |
| Pointer | Black, aluminium |
| Movement material | Stainless steel 1.4404 / AISI 316L |
Technical Data
